Intec ARGUS 155 (115552) Tripleplay DSL Tester

Overview

The Intec ARGUS 155 is a premium handheld multifunction tester that integrates VDSL2 (up to 30 MHz), ADSL (Annex A, B, J, L, M), and SHDSL (2, 4, and 8 wire) technologies along with Ethernet, ISDN PRI/E1, BRI/S/T/U, and POTS interfaces. As the only handheld tester and analyzer to combine all these capabilities in a single device without requiring module swaps, it delivers comprehensive testing solutions for complex telecommunications networks.

The ARGUS 155's Gigabit Ethernet interface (GigE) enables download speeds up to 200 Mbit/s via HTTP and FTP, comparable to fiber optic modem performance. Advanced cabling diagnostics identify shorts, opens, mismatches, wire pair delay, and polarity issues with precision.

Key Features

• VDSL2 support up to 30 MHz with integrated Vectoring capability
• ADSL testing for Annexes A, B, J, L, and M
• SHDSL testing for 2, 4, and 8 wire configurations
• Comprehensive ISDN support (PRI/E1 and BRI/S/T/U)
• Gigabit Ethernet interface with download speeds up to 200 Mbit/s
• Advanced Ethernet cabling tests and fault location capability
• Li-Ion battery pack or mains adapter power supply
• 18-key keypad with 4 cursor keys and 3 context-sensitive softkeys
• Color LCD display (QVGA 320×240 pixels) with backlight
• 6 LEDs for status indication plus Ethernet port LEDs
• Integrated handset with earpiece and microphone
• CE marked and compliant with safety standard EN 60950-1:2006-11
• RoHS conformant according to WEEE directive

Applications

• Advanced DSL network provisioning and acceptance testing
• Multi-technology service activation (VDSL2, ADSL, SHDSL)
• Network troubleshooting and fault isolation
• Ethernet infrastructure testing and verification
• ISDN network maintenance and diagnostics
• Copper line quality assessment
• Fiber-to-the-home (FTTH) gateway testing
