EXFO MAX-860G-100 Ethernet Tester
Request a quote
EXFO MAX-860G-100 is a portable handheld Ethernet tester with support for 10M to 100G testing, RFC2544, EtherBERT, and multistream traffic generation.
Product details
| Model | MAX-860G-100 |
| Manufacturer | EXFO |
| Category | Telecommunications Testers |
| Availability | Made to order |
Description
Overview
The EXFO MAX-860G-100 is a handheld Ethernet tester from the MAX-800 Series, designed for telecommunications technicians and engineers. It provides comprehensive Ethernet testing capabilities from 10M to 100G with an ultra-bright 8-inch multitouch display and lightweight, portable design suitable for field deployment.
Key Features
- Ethernet testing from 10M to 100G
- 8-inch multitouch color display (1280 × 800)
- EtherBERT, TGEN, BERT, and RFC2544 test applications
- EtherSAM (ITU-T Y.1564) for service activation and SLA evaluation
- Multistream traffic generation and monitoring
- IPv6 and MPLS support
- Dual-port testing capability
- Built-in connectivity: Gigabit Ethernet, WiFi, Bluetooth, and 3G/4G LTE via USB
- Lightweight and portable design for field technicians
Applications
- Ethernet network installation and testing
- Service activation and SLA verification
- Network troubleshooting and maintenance
- Field technician deployment for carrier networks
Specifications
| Maximum Ethernet Speed | 100G |
| Supported Speeds | 10M to 100G |
| Processor | Dual-core |
| Memory | 4 GB RAM |
| Storage | 64 GB flash memory |
| Display | 8-inch multitouch color (1280 × 800) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Dimensions | 210 mm × 254 mm × 66 mm (8.25 × 10 × 2.625 in) |
| Weight | 2.5 kg (5.6 lb) with battery |
