Siglent SSU5183A RF Mechanical Switch
Request a quote
Siglent SSU5183A is an RF mechanical switch with three SPDT switches, SMA female connectors, operating from DC to 18GHz with USB connectivity and SCPI control.
Product details
| Model | SSU5183A |
| Manufacturer | Siglent |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Siglent SSU5183A is an RF mechanical switch featuring three SPDT (single pole, dual throw) mechanical switches designed for multi-port testing in microwave and millimeter wave systems. It offers compact design, excellent RF characteristics, low insertion loss, and superior impedance matching.
Key Features
- Frequency range: DC to 18GHz
- Three SPDT mechanical switches (each with 1 common terminal switched to 1 of 2 numbered terminals)
- SMA female RF connectors
- USB connectivity and TTL control
- SCPI controllable via VISA and EasySSU software
- Compact design with low insertion loss
- Dimensions: 153 x 62.4 x 137.5mm (6 x 2.5 x 5.5 inches)
Applications
- Multi-port testing for microwave systems
- Millimeter wave testing applications
- Test port expansion for RF equipment
Specifications
| Frequency Range | 18 GHz |
| Connector Type | SMA(f) |
| Series | SSU5000A Series |
| Includes | RF Switch, User Manual, Power Adapter,USB Cable |
