Siglent SSM5342A RF Switch Matrix
Request a quote
Siglent SSM5342A RF switch matrix with 4 input and 12 output ports, supporting frequencies from 100kHz to 26.5GHz with LAN, USB, and Direct Control interfaces.
Product details
| Model | SSM5342A |
| Manufacturer | Siglent |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Siglent SSM5342A is an RF switch matrix designed to expand the number of test ports of network analyzers, signal sources, spectrum analyzers, and other equipment. It supports a simplified multi-port calibration algorithm for improved efficiency.
Key Features
- Frequency range: 100kHz - 26.5GHz
- 4 input ports and 12 output ports
- 3.5mm female RF connectors
- Maximum input DC voltage: 35V
- Maximum input power: 20 dBm
- Communication interfaces: LAN, USB Device, Direct Control
- Simplified multi-port calibration algorithm support
Applications
- Multi-port testing of network analyzers
- Signal source testing systems
- Spectrum analyzer test setups
- Microwave and millimeter wave testing systems
Specifications
| Frequency Range | 26.5 GHz |
| Connector Type | 3.5mm(f) |
| Series | SSM5000A Series |
| Number of Ports | 4 Input / 12 Output |
