Siglent SSM5321A RF Switch Matrix
Request a quote
Siglent SSM5321A RF switch matrix with 2 input and 6 output ports, supporting frequencies from 100kHz to 26.5GHz with 3.5mm connectors.
Product details
| Model | SSM5321A |
| Manufacturer | Siglent |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Siglent SSM5321A is an RF switch matrix designed to expand the number of test ports for network analyzers, signal sources, spectrum analyzers, and other RF equipment. It features 2 input ports and 6 output ports with 3.5mm female connectors, supporting a wide frequency range from 100kHz to 26.5GHz.
Key Features
- Frequency range: 100kHz to 26.5GHz
- 2 input ports and 6 output ports
- 3.5mm female RF connectors
- Maximum input power: 20 dBm
- Maximum input DC voltage: 35 V
- Supports simplified multi-port calibration algorithm
- Multiple interfaces: LAN, USB Device, Direct Control
Applications
- Network analyzer port expansion
- Signal source routing
- Spectrum analyzer test port routing
- Automated RF test systems
- Millimeter-wave testing
Specifications
| Frequency Range | 26.5 GHz |
| Connector Type | 3.5mm(f) |
| Series | SSM5000A Series |
| Number of Ports | 2 Input / 6 Output |
