Keysight N1810TL 26.5GHz Coaxial Switch

Overview

The Keysight N1810TL is a high-frequency latching coaxial switch engineered for millimeter-wave and broadband RF applications. This model operates from DC to 26.5 GHz with superior RF performance, making it suitable for advanced test and measurement environments requiring frequency coverage up to 26.5 GHz.

Key Features

• Single-pole double-throw (SPDT) configuration
• Operating frequency: DC to 26.5 GHz
• Isolation: >120 dB at 4 GHz, 70 dB at 26.5 GHz
• Low SWR: <1.10 at 4 GHz, <1.60 at 26.5 GHz
• Low insertion loss: <0.27 dB at 4 GHz, <0.80 dB at 26.5 GHz
• 24V coil supply with built-in current interrupt
• D-subminiature 9-pin female connector
• Operating life: 2 million cycles
• Excellent repeatability and long life span

Applications

• Millimeter-wave measurement systems
• High-frequency RF test equipment
• Broadband communication systems
• Advanced automated test environments
