Keysight L7106B/024/100 Multiport Coaxial Switch
Request a quote
Keysight L7106B/024/100 multiport RF switch with DC to 20 GHz frequency range, SP6T configuration, 0.03 dB insertion loss repeatability, and 90 dB isolation.
Product details
| Model | L7106B/024/100 |
| Manufacturer | Keysight |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Keysight L7106B/024/100 is a terminated multiport electromechanical coaxial switch designed for RF and microwave signal routing and testing. This economically-priced switch is ideal for manufacturing test engineers working on system integration and signal monitoring applications.
Key Features
- SP6T configuration, terminated
- 24 V DC control logic (Option 024)
- Solder terminals (Option 100)
- Electronic position indicator
- Magnetic latching with current interrupt capability
- DC to 20 GHz frequency range
- Unmatched isolation: typically 90 dB at 12 GHz
- Operating life: 5 million cycles (typical)
- Guaranteed repeatability: 0.03 dB up to 2 million cycles
Applications
- RF and microwave signal routing
- Automated test equipment (ATE)
- Manufacturing test systems and integration
- Signal monitoring and distribution
Specifications
| Series | L Series |
