Keysight 8764C/024 5-Port Coaxial Switch
Request a quote
Keysight 8764C/024 is a broadband 5-port coaxial switch operating from DC to 26.5 GHz with excellent electrical performance, low insertion loss, and high isolation.
Product details
| Model | 8764C/024 |
| Manufacturer | Keysight |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Keysight 8764C/024 is a broadband, unterminated 5-port coaxial switch designed for RF and microwave instrumentation. It offers excellent electrical and mechanical performance with outstanding repeatability and long operational life, making it ideal for automatic test equipment and laboratory applications.
Key Features
- 5-port unterminated coaxial switch with broadband operation from DC to 26.5 GHz
- 24V solenoid configuration without TTL logic
- Insertion loss: less than 0.20 dB to 2 GHz, less than 0.5 dB to 18 GHz, less than 1.25 dB to 26.5 GHz
- Isolation: better than 90 dB to 18 GHz, better than 50 dB to 26.5 GHz
- SWR (through line) maintained across the frequency range
- High repeatability: less than 0.03 dB typical
- Long operational life rated for more than 1 million cycles
- Current interrupt and position indication capability
Applications
- Automatic test equipment (ATE) systems
- RF and microwave signal routing
- Broadband measurement systems
