Keysight 8762C/T24 Coaxial Switch
Request a quote
Keysight 8762C/T24 is a DC to 18 GHz SPDT coaxial switch with TTL/5V CMOS logic, high isolation (>90 dB), and low insertion loss (<0.5 dB to 18 GHz).
Product details
| Model | 8762C/T24 |
| Manufacturer | Keysight |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Keysight 8762C/T24 is a single-pole double-throw (SPDT) coaxial switch operating from DC to 18 GHz with integrated TTL/5V CMOS logic control. It combines excellent electrical and mechanical performance with digital control capability, making it ideal for automated test systems requiring direct logic interface.
Key Features
- Frequency range: DC to 18 GHz
- SPDT configuration with 24V solenoids and TTL/5V CMOS logic
- Isolation: >90 dB to 18 GHz, >50 dB to 26.5 GHz
- Insertion loss: <0.25 dB to 2 GHz, <0.5 dB to 18 GHz, <1.25 dB to 26.5 GHz
- TTL/5V CMOS compatible for automated control
- Low SWR and exceptional repeatability
Applications
- Automated test equipment (ATE) with logic control
- RF and microwave test systems with digital switching
- Broadband switching in communication systems
- Logic-controlled RF switching applications
