Keysight 8762A/T24 Coaxial Switch
Request a quote
Keysight 8762A/T24 TTL-compatible SPDT coaxial switch delivers DC to 4 GHz performance with >100 dB isolation, 24V solenoids, and <0.25 dB insertion loss.
Product details
| Model | 8762A/T24 |
| Manufacturer | Keysight |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Keysight 8762A/T24 is a TTL-compatible SPDT coaxial switch designed for broadband RF/microwave applications from DC to 4 GHz. This model features 24V solenoid actuators with TTL/CMOS logic compatibility, providing excellent electrical performance and mechanical reliability for automated test and measurement applications.
Key Features
- SPDT configuration (Single Pole Double Throw)
- Frequency range: DC to 4 GHz
- Isolation: >100 dB to 4 GHz
- Insertion loss: <0.2 dB to 2 GHz, <0.25 dB to 4 GHz
- 24V solenoid actuators with TTL/5V CMOS logic compatibility
- SMA female connectors
- Excellent insertion loss repeatability (0.03 dB typical)
Applications
- Automated RF/microwave test systems
- Precision measurement equipment
- Digital-controlled broadband switching
