Keysight 8762A/T15 Coaxial Switch
Request a quote
Keysight 8762A/T15 TTL-compatible SPDT coaxial switch provides DC to 4 GHz operation with >100 dB isolation, 15V solenoids, and low insertion loss.
Product details
| Model | 8762A/T15 |
| Manufacturer | Keysight |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Keysight 8762A/T15 is a TTL-compatible SPDT coaxial switch engineered for broadband RF/microwave applications from DC to 4 GHz. It features 15V solenoid actuators with 5V/TTL logic compatibility, making it ideal for automated test systems and laboratory instrumentation that require digital control integration.
Key Features
- SPDT configuration (Single Pole Double Throw)
- Frequency range: DC to 4 GHz
- Isolation: >100 dB to 4 GHz
- Insertion loss: <0.2 dB to 2 GHz, <0.25 dB to 4 GHz
- 15V solenoid actuators with TTL/5V CMOS logic compatibility
- SMA female connectors
- Excellent insertion loss repeatability (0.03 dB typical)
Applications
- Automated RF test systems
- Laboratory measurement equipment
- Digital-controlled signal routing
Specifications
| Frequency Range | DC to 4 GHz |
| Switch Type | SPDT (Single Pole Double Throw) |
| Insertion Loss | <0.20 dB (DC to 2 GHz), <0.25 dB (2 to 4 GHz) |
| Isolation Between Ports | >100 dB (DC to 4 GHz) |
| SWR Through Line | <1.10 (DC to 2 GHz), <1.20 (2 to 4 GHz) |
| Connectors | SMA (female) |
| Solenoid Voltage | 15 VDC |
| Logic Compatibility | TTL/5V CMOS |
| Insertion Loss Repeatability | 0.03 dB typical (1,000,000 cycles) |
