Keysight 8762A/024 Coaxial Switch
Request a quote
Keysight 8762A/024 SPDT coaxial switch offers DC to 4 GHz broadband operation with >100 dB isolation, <0.2 dB insertion loss, and long mechanical life.
Product details
| Model | 8762A/024 |
| Manufacturer | Keysight |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Keysight 8762A/024 is a coaxial SPDT switch designed for broadband RF/microwave applications up to 4 GHz. This model features 24V solenoids without TTL logic, providing excellent electrical and mechanical performance with high isolation, low SWR, and exceptional repeatability over extended use.
Key Features
- SPDT configuration (Single Pole Double Throw)
- Frequency range: DC to 4 GHz
- Isolation: >100 dB to 4 GHz
- Insertion loss: <0.2 dB to 2 GHz, <0.25 dB to 4 GHz
- 24V solenoid actuators (non-TTL)
- SMA female connectors
- Long mechanical life with excellent repeatability
Applications
- Test and measurement systems
- RF/microwave signal routing
- Automated test equipment
Specifications
| Series | 8762xx Series |
