Keysight 8762A/015 Coaxial Switch
Request a quote
Keysight 8762A/015 is a 15V single-pole double-throw coaxial switch for 50 ohm systems operating DC to 4 GHz, with isolation exceeding 100 dB and low insertion loss.
Product details
| Model | 8762A/015 |
| Manufacturer | Keysight |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Keysight 8762A/015 is a single-pole, double-throw coaxial switch with 15V solenoids, designed for 50 ohm systems operating from DC to 4 GHz. It delivers excellent electrical performance with high isolation and low insertion loss.
Key Features
- 15V solenoid operation (TTL logic not available)
- SPDT configuration for flexible signal routing
- Exceptional isolation performance exceeding 100 dB
- Low insertion loss across the operating frequency range
- Reliable, long-life mechanical switching
Applications
- RF test equipment
- Microwave signal routing
- Automated testing systems
Specifications
