Keysight 87106A/T24/161 Multiport Coaxial Switch
Request a quote
Keysight 87106A/T24/161 is a SP6T multiport coaxial switch with DC to 4 GHz range, featuring 0.03 dB repeatability and 10 million cycle operating life.
Product details
| Model | 87106A/T24/161 |
| Manufacturer | Keysight |
| Category | RF Switches |
| Availability | Made to order |
Description
Overview
The Keysight 87106A/T24/161 is a SP6T multiport coaxial switch designed for automated test and measurement, signal monitoring, and routing applications. The switch provides excellent insertion loss repeatability and isolation necessary for high-performance test systems. With an operating life of 10 million cycles and guaranteed 0.03 dB repeatability up to 5 million cycles, it reduces calibration requirements and improves test system uptime.
Key Features
- SP6T configuration with magnetic latching
- DC to 4 GHz frequency range
- Terminated ports
- Operating life of 10 million cycles
- Guaranteed repeatability of 0.03 dB up to 5 million cycles
- Excellent RF isolation
- Opto-electronic indicators and interrupts
- TTL/5V CMOS compatible
Configuration Options
- (T24) 24 VDC bias with TTL logic
- (161) 16 pin DIP socket and connector with 24 inch ribbon cable, bare wire interface
Applications
- Automated test systems (ATS)
- Signal monitoring and routing
- High-performance measurement systems requiring precision switching
