Rohde & Schwarz FSUP50 Signal and Spectrum Analyzer
Request a quote
Rohde & Schwarz FSUP50 combines phase noise testing with spectrum analysis up to 50 GHz, featuring low-noise DC sources for oscillator and synthesizer characterization.
Product details
| Model | FSUP50 (1166.3505.51) |
| Manufacturer | Rohde & Schwarz |
| Category | RF & Microwave Test Equipment |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FSUP50 is a unique combination of high-end spectrum and signal analyzer with dedicated phase noise testing capabilities. Designed for development and production applications, it provides a single-box solution for measuring oscillators and synthesizers. The integrated low-noise DC sources enable flexible test configurations for supply and tuning voltage applications.
Key Features
- Frequency range up to 50 GHz (8, 26.5, or 50 GHz models available)
- Extended frequency capability up to 110 GHz with external mixers
- Low-noise DC outputs for supply and tuning voltages
- Phase noise measurement with maximum measurement flexibility
- Noise figure and gain measurements
- Digital and analog modulated signal analysis
Applications
- Oscillator and synthesizer characterization
- Component and circuit development testing
- Production quality assurance measurements
- Signal integrity validation
Specifications
| Frequency Range | Up to 50 GHz (base models: 8, 26.5, or 50 GHz) |
| Extended Frequency | Up to 110 GHz with external mixers |
| DC Source Outputs | Low-noise outputs for supply and tuning voltages |
| Analyzer Type | Phase noise tester with spectrum and signal analysis |
| Measurement Capabilities | Phase noise, noise figure, gain, modulation analysis |
