Noise Com UFX7112A Programmable Noise Generator

Overview

The Noise Com UFX7000A Series instruments are amplified noise sources designed for precision RF and microwave testing. They produce white Gaussian noise with optimized flatness and configurable output power levels. These instruments are microprocessor-controlled and feature a 6.25" color TFT display for local operation, with remote control available via IEEE-488 bus, Ethernet, or RS232 for integration into automated test systems.

Key Features

• Output white Gaussian noise with exceptional flatness
• Attenuation range 0 to 127 dB in 1 dB steps (optional 0.1 dB steps)
• Type N, BNC, or SMA connectors available
• Optional signal path attenuators
• SP6T RF switch allows flexible filter path selection
• Band pass, low pass, high pass, or notch filters available
• 6.25" color VGA TFT touch screen display with keyboard
• Standard Ethernet remote control or optional IEEE-488 GPIB interface
• Microprocessor-controlled with optional rear panel connectors
• Fold-down feet for bench-top use
• Operating temperature: -10°C to +65°C

Applications

• Eb/No, C/N, and SNR testing
• Bit error rate (BER) testing
• Disk drive and receiver testing
• GPS receiver testing and validation
• CATV and cable system testing
• Spectrum analyzer calibration
• Filter and component testing
• EMI and interference testing
• Military jamming simulation
