Keysight N4985A System Amplifier
Request a quote
Keysight N4985A — high-performance broadband RF amplifier system operating from 100 kHz to 50 GHz with excellent power gain for lab and production testing.
Product details
| Model | N4985A |
| Manufacturer | Keysight |
| Category | RF & Microwave Test Equipment |
| Availability | Made to order |
Description
Overview
The Keysight N4985A series system amplifiers are high-performance broadband amplifiers offering excellent power and gain from 100 kHz to 50 GHz. The amplifiers are self-contained units that plug directly into standard AC power sources, making them suitable for both bench-top and production environments.
Key Features
- High-performance broadband gain from 100 kHz to 50 GHz
- Excellent output power and gain characteristics
- Compact, self-contained design
- Standard AC power operation
Applications
- Bench-top laboratory work
- Production line testing
- Frequency and time domain applications
- Saturated RF amplifier testing
- TWT amplifier drive applications
- Antenna system amplification
Specifications
| Output Power | +20dBm |
| Gain | 27dB |
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | 100kHz <= 1MHz |
| Connector Type | Type N-Female (Plug) |
