Flann 17081-30 Fixed Attenuator
Request a quote
The Flann 17081-30 is a fixed waveguide attenuator providing 30 dB attenuation with low VSWR and 0.5W power handling for X-band RF/microwave testing.
Product details
| Model | 17081-30 |
| Manufacturer | Flann |
| Category | RF & Microwave Test Equipment |
| Availability | Made to order |
Description
Overview
The Flann 17081-30 is a fixed waveguide attenuator from the Series 081 line, designed for RF and microwave applications. This model operates in the X-band frequency range (9.84 to 15.0 GHz) using WG17 waveguide and provides a fixed attenuation of 30 dB with exceptional VSWR performance and durability.
Key Features
- 30 dB fixed attenuation with ±10% tolerance
- Very low VSWR of 1.2 (better than)
- Full X-band waveguide coverage (9.84 - 15.0 GHz)
- 0.5W mean power handling
- Compact 120mm flange-to-flange length
- Low frequency sensitivity
Applications
- RF and microwave signal conditioning
- Test and measurement systems
- Power level control and attenuation
- Impedance matching networks
Specifications
| 17081 | 9.84 - 15.017120751.11.20.5120 |
| Standard Attenuation Values | Suffix |
| 3 dB | 03 |
| 6 dB | 06 |
| 10 dB | 10 |
| 20 dB | 20 |
| 30 dB | 30 |
