Dwyer Instruments 26150 Temperature/Process Controller
Request a quote
Dwyer Instruments 26150 is a dual-input temperature and process controller with multiple input types and relay/current outputs.
Product details
| Model | 26150 |
| Manufacturer | Dwyer Instruments |
| Category | Process Controllers |
| Availability | Made to order |
Description
Overview
The Dwyer Instruments 26150 is a dual-input temperature and process controller designed for versatile measurement and control applications. It features multiple selectable input types, relay and current outputs, and an alarm function for process monitoring and protection.
Key Features
- Selectable inputs: Thermocouple, RTD, DC voltage, or DC current
- Output A: 0-20 mA DC proportional current, scalable into 600 Ohms maximum
- Alarm relay output: SPST, 3 A @ 240 VAC resistive
- Two 4-digit, 7-segment LED displays (0.56" high)
- Accuracy: ±0.25% of span, ±1 least significant digit
- NEMA 4X (IP66) front panel rating for washdown environments
- Multiple control relay options for switching applications
Applications
- Temperature monitoring and control in industrial processes
- Multi-input measurement and regulation systems
- Process protection and alarm functions
- Washdown and humid environment operations
Specifications
| Selectable Inputs | Thermocouple, RTD, DC voltage, DC current |
| Accuracy | ±0.25% of span, ±1 least significant digit |
| Display | Two 4-digit, 7-segment LED displays, 0.56" high |
| Input Impedance (Thermocouple) | 3 Megohms minimum |
| Input Impedance (Voltage) | 5000 Ohms |
| Input Impedance (Current) | 10 Ohms |
| Input Impedance (RTD Current) | 200 µA maximum |
| Output A | 0-20 mA DC proportional current, scalable into 600 Ohms maximum |
| Alarm Output | SPST relay, 3 A @ 240 VAC resistive |
| Control Relay Output | SPDT, 10 A @ 240 VAC resistive |
| Supply Voltage | 100-240 VAC nominal (±10% to ±15%), 50-400 Hz; 132-240 VDC (±10% to ±20%) |
| Operating Temperature | -10 to 55°C (14 to 131°F) |
| Front Panel Rating | NEMA 4X (IP66) |
| Weight | 369 g (13 oz) |
