Dwyer Instruments 26130 Temperature/Process Controller
Request a quote
Dwyer 26130 dual-display temperature and process controller with selectable inputs (thermocouple, RTD, voltage, current), relay control, and ±0.25% accuracy.
Product details
| Model | 26130 |
| Manufacturer | Dwyer Instruments |
| Category | Process Controllers |
| Availability | Made to order |
Description
Overview
The Dwyer Instruments 26130 is a compact temperature and process controller with dual 4-digit LED displays and multiple input options. It supports thermocouple, RTD, DC voltage, and DC current inputs for flexible process monitoring, with relay control outputs and alarm functionality for industrial applications.
Key Features
- Selectable inputs: Thermocouple, RTD, DC voltage, or DC current
- Dual 4-digit, 7-segment LED displays (0.56 inches high)
- Relay control output (SPDT, 10A @ 240VAC) and separate alarm relay
- High accuracy at ±0.25% of span ±1 LSB
- NEMA 4X (IP66) front panel rating for wet and corrosive environments
Applications
- Temperature monitoring and regulation
- Industrial process control and automation
- Environmental and facility monitoring systems
Specifications
| Selectable Inputs | Thermocouple, RTD, DC voltage, DC current |
| Display | Two 4-digit, 7-segment LED (0.56 inches high) |
| Accuracy | ±0.25% of span ±1 LSB |
| Output A | Relay SPDT, 10A @ 240VAC resistive |
| Alarm Output | Relay SPST, 3A @ 240VAC resistive |
| Supply Voltage AC | 100-240VAC nominal (+10% -15%, 50-400Hz) |
| Supply Voltage DC | 132-240VDC (+10% -20%) |
| Operating Temperature | -10°C to 55°C (14°F to 131°F) |
| Input Impedance - Thermocouple | 3 MΩ minimum |
| Input Impedance - Voltage | 5000 Ω |
| Input Impedance - Current | 10 Ω |
| RTD Current | 200 µA maximum |
| Front Panel Rating | NEMA 4X (IP66) |
| Weight | 13 oz (369 g) |
