Ralston Instruments XTHP-2MSA Hydraulic Hand Pump

Overview

The Ralston Instruments XTHP-2MSA is a 10,000 psi hydraulic hand pump designed for pressure calibration and testing. It features stainless steel construction for all wetted parts, ensuring stable pressure at high pressures, and includes a priming module for quick filling before pumping.

Key Features

• Generates up to 10,000 psi without requiring a stroke limiting knob
• Stainless steel wetted parts ensure stable pressure at high pressures
• Priming module for quick hose and device filling
• Quick-test XT 10,000 psi adapters and hoses for hand-tight field connections
• Lightweight (3 lb/1.4 kg) and compact design for one-handed operation
• Well-balanced design with pressurized section below reservoir
• Compatible with water, ethylene glycol, antifreeze, windshield wiper fluid, hydraulic oil, mineral oil, and alcohol
• Shock-resistant and chemically resistant reservoir material
• Metal-to-metal bleed/vent valve for excellent sealing at any pressure
• Made in the USA

Applications

• Pressure calibration and testing
• Field testing of pressure instruments
• Portable pressure generation for service and maintenance

Included Accessories

• XTHP Hydraulic hand pump
• 3 ft Quick-test test hose
• 1/4" Male NPT process adapter
• Fluid bottle
