Ralston Instruments XTHP-0000 Hydraulic Hand Pump
Request a quote
Ralston Instruments XTHP-0000 generates up to 10,000 psi for pressure calibration and testing. Lightweight stainless steel construction with quick-test adapters and included bottle.
Product details
| Model | XTHP-0000 |
| Manufacturer | Ralston Instruments |
| Category | Pressure Accessories |
| Availability | Made to order |
Description
Overview
The Ralston Instruments XTHP-0000 is a 10,000 psi hydraulic hand pump engineered for pressure calibration and equipment testing. Its stable pressure generation and compact design make it ideal for field applications where portability is essential. The pump features all stainless steel wetted parts for durability and compatibility with a wide range of hydraulic fluids.
Key Features
- Generates pressure up to 10,000 psi without stroke limiting mechanisms
- Stainless steel construction for stable pressure especially at high pressures
- Priming module allows quick fluid fill before pumping
- Quick-test XT adapters and hoses for hand-tight field connections
- Lightweight at 3 lb (1.4 kg) with one-hand operation capability
- Well-balanced design with pressurized section below reservoir
- Compatible with water, ethylene glycol, antifreeze, windshield wiper fluid, hydraulic oil, mineral oil, and alcohol
- Reservoir material highly resistant to shock, extreme temperature, and chemical exposure
- Metal-to-metal bleed/vent valve for excellent sealing at any pressure
- Made in the USA
Applications
- Pressure gauge and transducer calibration
- Field testing of pressure systems
- Portable pressure source for equipment commissioning
- Maintenance and troubleshooting applications
Included Accessories
- XTHP Hydraulic hand pump
- 3 ft Quick-test test hose
- 1/4" Male NPT process adapter
- Bottle
Specifications
| Maximum Pressure | 10,000 psi (70 MPa) |
| Weight | 3 lb (1.4 kg) |
| Wetted Parts Material | Stainless steel |
| Included Hose | 3 ft Quick-test test hose |
| Process Connection | 1/4" Male NPT adapter |
| Compatible Fluids | Water, hydraulic oil, antifreeze, ethylene glycol, mineral oil, windshield wiper fluid, alcohol |
| Bleed Valve Type | Metal-to-metal seat |
| Country of Origin | USA |
