Keysight N6700A Modular Power System
Request a quote
Keysight N6700A — compact 1U modular power system with up to 4 configurable outputs for ATE and test applications, supporting GPIB, LAN, and USB connectivity.
Product details
| Model | N6700A |
| Manufacturer | Keysight |
| Category | Power Supplies & Electronic Loads |
| Availability | Made to order |
Description
Overview
Note: This product has been replaced by the Keysight N6700C. The Keysight N6700A is a compact, modular power system designed for ATE and production test environments. It simplifies test-system assembly, cabling, programming, and operation by providing configurable DC power in a compact 1.75-inch form factor.
Key Features
- Compact 1U form factor accommodates up to 4 DC power modules
- Flexible, modular design — mix and match power levels and performance for optimized investment
- Includes both performance and value module options
- Fast command processing for improved throughput
- Multiple connectivity options: GPIB, LAN, USB
- Outputs can be sequenced
- Outputs can be connected in series or parallel
- Optional output disconnect relays and High Speed Test Extensions
Applications
- ATE systems for R&D, design validation, and manufacturing
- Bias power and stimulus for subassemblies and final products
- Production test environments requiring compact, flexible power solutions
Specifications
| Form Factor | 1U (1.75 in. high) |
| Module Slots | Up to 4 |
| Interfaces | GPIB, LAN, USB |
| Output Modes | Sequenced, series, or parallel |
| Optional Features | Output disconnect relays, High Speed Test Extensions |
