Keysight E36104A DC Power Supply
Request a quote
Keysight E36104A is a compact 35V/1A DC power supply with 0.05% accuracy, OLED display, and USB/LAN connectivity.
Product details
| Model | E36104A |
| Manufacturer | Keysight |
| Category | Power Supplies & Electronic Loads |
| Availability | Made to order |
Description
Overview
The Keysight E36104A is a compact, benchtop DC power supply from the E36100 Series, delivering 35 V and 1 A (35 W maximum). It is engineered for laboratory and production testing of low-power devices, providing exceptional accuracy and low-noise output for demanding applications that require stable, reliable power.
Key Features
- Output: 0–35 V, 0–1 A, 35 W
- Compact 2U, ¼-rack form factor
- High-contrast OLED display, viewable from any angle
- Programming accuracy: 0.05% + 12 mV voltage, 0.05% + 0.6 mA current
- Readback accuracy: 0.05% + 8 mV voltage, 0.05% + 0.5 mA current
- Low ripple and noise: 4 mV rms, 60 mV peak-to-peak
- USB and LAN (LXI Core) connectivity for remote control
- Overvoltage, overcurrent, and overtemperature protection
- Low-power current measurement capability
Applications
- Device testing and validation in development labs
- Powering sensitive analog and digital circuits
- Burn-in and reliability testing
- Automated test systems via SCPI or IVI programming
Specifications
| Maximum Voltage | 35V |
| Maximum Current | 1A |
| Channel/Port Count | 1 |
