Keysight E36102A DC Power Supply
Request a quote
Keysight E36102A is a compact DC power supply delivering 6V/5A with 0.05% programming accuracy, OLED display, and USB/LAN connectivity for automated device testing.
Product details
| Model | E36102A |
| Manufacturer | Keysight |
| Category | Power Supplies & Electronic Loads |
| Availability | Made to order |
Description
Overview
The Keysight E36102A is a compact DC power supply designed for powering low-power devices with exceptional accuracy and low noise. Housed in a 2U, ¼-rack form factor, this linear power supply combines precision voltage and current regulation with advanced connectivity options, making it ideal for automated testing, research, and development applications.
Key Features
- Output: 6V at 5A (30W)
- Programming accuracy: 0.05% + 3mV (voltage), 0.05% + 5mA (current)
- Low noise: 350µV rms ripple and noise (20 Hz to 20 MHz)
- High-contrast OLED display with wide viewing angle
- USB and LAN (LXI Core) connectivity for remote control
- Overvoltage, overcurrent, and overtemperature protection
- Multiple control interfaces: front-panel, web browser, SCPI, IVI drivers
- BenchVue software integration for visualization and logging
Applications
- Device power-up and burn-in testing
- Automated research and development
- Precision laboratory measurements
- Educational and training applications
Specifications
| Maximum Voltage | 6V |
| Maximum Current | 5A |
| Maximum Power | 30W |
| Channel/Port Count | 1 |
| Phases | 1 |
