Delta Elektronika SM18-220 Power Supply
Request a quote
Delta Elektronika SM18-220 is an 18 V / 220 A programmable DC power supply with Ethernet interface, auto-ranging output, and excellent efficiency.
Product details
| Model | SM18-220 |
| Manufacturer | Delta Elektronika |
| Category | Power Supplies & Electronic Loads |
| Availability | Made to order |
Description
Overview
The Delta Elektronika SM18-220 is a high-performance programmable DC power supply offering 18 V and 220 A output capability. With excellent efficiency, stability, and flexible control options, the SM18-220 is designed for applications requiring precise power delivery and multiple control interfaces. The unit supports both single-phase and three-phase grid power input for maximum flexibility.
Key Features
- Output range: 0 - 18 V, 0 - 220 A
- Auto-ranging power output covers multiple traditional power supply ranges
- Standard Ethernet interface for remote control and monitoring
- Front panel control with menu-driven operations
- Operation on single-phase or three-phase input voltage
- Excellent dynamic response to load changes
- EMC compliance exceeding CE requirements
- Temperature-controlled fan with low audible noise
- Durable digital encoders for voltage and current adjustment
- Protected against overload and short circuit conditions
- Designed for long-life operation at full power
Available Options
- Software control and interface cards
- High-speed programming capability
- Two-quadrant output with PowerSink functionality
Applications
- Industrial power system testing and commissioning
- Laboratory and development applications
- Battery charging and testing
- Electronic load testing
Specifications
| Voltage Range | 0 - 18 V |
| Current Range | 0 - 220 A |
| Power Output | 3,960 W |
| Input Voltage | Single-phase or three-phase AC |
| Control Interfaces | Front panel, Ethernet, optional interface cards |
| EMC Compliance | Exceeds CE requirements |
| Protection | Overload and short circuit |
