Teledyne LeCroy HDO4K-SMBUS TD Trigger & Decode Option
Request a quote
Teledyne LeCroy HDO4K-SMBUS TD enables SMBus protocol triggering and decoding on HDO4000A oscilloscopes for power management and battery analysis.
Product details
| Model | HDO4K-SMBUS TD |
| Manufacturer | Teledyne LeCroy |
| Category | Oscilloscope Accessories |
| Availability | Made to order |
Description
Overview
The HDO4K-SMBUS TD is a software option that adds System Management Bus (SMBus) protocol support to Teledyne LeCroy HDO4000A oscilloscopes. This option allows engineers to trigger on and decode SMBus signals for analysis of power management, battery monitoring, and system communication.
Key Features
- SMBus protocol trigger and decode capability
- System Management Bus format support
- Integrated with HDO4000A 12-bit oscilloscope platform
- Real-time protocol analysis and display
Applications
- Power supply management circuit analysis
- Battery monitoring system debugging
- Thermal management system validation
- System communication protocol testing
Specifications
| Series | HDO4000 Series |
