Tektronix P76CA-292 Coaxial Adapter
Request a quote
Tektronix P76CA-292 is a 33 GHz coaxial adapter with 2.92mm female connectors for high-bandwidth differential measurements on P7600 Series oscilloscope probes.
Product details
| Model | P76CA-292 |
| Manufacturer | Tektronix |
| Category | Oscilloscope Accessories |
| Availability | Made to order |
Description
Overview
The Tektronix P76CA-292 is a 33 GHz bandwidth coaxial adapter featuring 2.92mm female connectors. It extends the P7600 Series probe capabilities, allowing the probe to operate as a differential input channel and effectively double the number of simultaneous differential signal measurements on an oscilloscope. The adapter is calibrated at the input connectors for optimal frequency response to the probe tip.
Key Features
- 33 GHz bandwidth
- 2.92mm female connectors
- Coaxial design for high-speed signal measurement
- Calibrated at input connectors for accurate frequency response
- Supports cable pairs with low time delay to preserve full bandwidth
- Compatible with P7600 Series TriMode probes
Applications
- Differential signal measurement on high-speed circuits
- Custom cable integration for signal characterization
- Extension of P7600 Series probe measurement capabilities
Specifications
| For Use With | P7600 Series Probes |
| Series | P7600 Series |
| Bandwidth | 33 GHz |
