Rohde & Schwarz ZISO-Z203 Wide Square Pin Tip
Request a quote
Rohde & Schwarz ZISO-Z203 wide square pin probe tip with 100x attenuation for oscilloscope measurements up to ±2.5 kV RMS with CAT III 1000 V safety.
Product details
| Model | ZISO-Z203 |
| Manufacturer | Rohde & Schwarz |
| Category | Oscilloscope Accessories |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz ZISO-Z203 is a wide square pin (WSQPIN) probe tip for oscilloscopes designed for very high voltage measurements up to ±2.5 kV RMS. With 100x attenuation and larger creepage distances, this tip accommodates high voltage scenarios while maintaining isolation and safety with a CAT III 1000 V rating.
Key Features
- Wide square pin (WSQPIN) connector for high voltage access, 5.08 mm pitch
- 100x attenuation with ±1 kV RMS / ±3 kV peak rating (supports up to ±2.5 kV RMS)
- 40 MΩ input impedance for high voltage measurements
- CAT III 1000 V safety rating with isolation caps on probe tips
- Large creepage distance design for high voltage isolation
- Safe attach feature with quick lever for secure, tool-free attachment
Applications
- Very high voltage measurements (up to ±2.5 kV RMS)
- Power electronics and high voltage circuit testing
- Design verification requiring isolation and creepage compliance
Specifications
| Type | Tip |
| For Use With | ZISO Series |
| Series | ZISO Series |
| Alternate Product Number | 1803.4400.02 |
| Bandwidth | 1 GHz |
| Attenuation | 100X |
| Connector Type | WSQPIN |
| Input Impedance | 40 MΩ |
| Maximum Input Voltage | 3500 V |
| Operating Temperature Range | 0-40°C |
