Rohde & Schwarz RTO-K50 Triggering and Decoding, Manchester/NRZ
Request a quote
Rohde & Schwarz RTO-K50 module provides Manchester/NRZ protocol triggering and decoding for RTO oscilloscopes, supporting up to 50 frame formats with 5 Gbit/s data rates.
Product details
| Model | RTO-K50 |
| Manufacturer | Rohde & Schwarz |
| Category | Oscilloscope Accessories |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz RTO-K50 is a hardware-accelerated triggering and decoding module for Rohde & Schwarz RTO and RTE oscilloscopes. It enables decoding of Manchester and NRZ-coded serial protocols with configurable frame formats and data rates up to 5 Gbit/s.
Key Features
- Configurable protocol frames including preamble, frame ID, data, CRC, and more
- Display of decoded telegrams as color-coded bus signals or in tabular form
- Triggering on start of frame, frame ID, and data with maximum data rate of 50 Mbit/s
- Support for up to 50 different frame formats
- Fast eye-diagram mask testing with standard mask test functionality
Applications
- Manchester and NRZ protocol validation and debugging
- Serial communication analysis and troubleshooting
- Multi-format protocol development and testing
Specifications
| Type | Trigger and Decode Bundle |
| Series | RTO Series |
| Alternate Product Number | 1329.7531.02 |
| Series Compatibility | RTO Series |
