Rohde & Schwarz MXO3-B105 Memory Option
Request a quote
Rohde & Schwarz MXO3-B105 memory option expands MXO 3 oscilloscope storage to 500 million points for extended waveform capture.
Product details
| Model | MXO3-B105 |
| Manufacturer | Rohde & Schwarz |
| Category | Oscilloscope Accessories |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz MXO3-B105 memory option expands the storage capacity of the MXO 3 series oscilloscope, enabling longer recording times and higher-resolution waveform captures. With this option, users can acquire up to 500 million points per acquisition.
Key Features
- 500 million points maximum memory with 4 active channels (single capture)
- 500 million points maximum memory with 2 active channels (continuous operation)
- Expanded segmentation capabilities for multi-trigger acquisition
- Supports decimation and high-definition (HD) capture modes
Applications
- Long-duration signal monitoring and recording
- High-resolution analysis of complex waveforms
- Continuous data acquisition in automated test systems
Specifications
| Type | Memory Option |
| For Use With | MXO 3 Series |
| Series | MXO 3 Series |
| Alternate Product Number | 1335.3105.03 |
