RIGOL DS8000-R-FLEX FlexRay Serial Bus Triggering and Analysis Option
Request a quote
RIGOL DS8000-R-FLEX is a FlexRay triggering option for DS8000-R oscilloscopes, supporting automotive bus analysis up to 10 Mb/s with advanced trigger conditions.
Product details
| Model | DS8000-R-FLEX |
| Manufacturer | RIGOL |
| Category | Oscilloscope Accessories |
| Availability | Made to order |
Description
Overview
The RIGOL DS8000-R-FLEX is a FlexRay serial bus triggering and analysis option for DS8000-R series compact oscilloscopes. FlexRay is a high-speed, fault-tolerant automotive communication protocol. This option enables triggering and analysis of FlexRay signals at rates up to 10 Mb/s, supporting complex trigger conditions for automotive network debugging and validation.
Key Features
- FlexRay serial bus triggering up to 10 Mb/s
- Triggers on position: TSS End, FSS_BSS End, FES End, DTS End
- Triggers on frame types: Null, Sync, Start, All
- Triggers on symbol, CAS/MTS, WUS, and error conditions
- Source channel: CH1–CH4
Applications
- Automotive FlexRay bus debugging and validation
- In-vehicle network protocol analysis
- Safety-critical system communication verification
Specifications
| Series | DS8000-R Series |
