RIGOL DS8000-R-AUTO CAN/LIN Serial Bus Trigger and Analysis Option
Request a quote
RIGOL DS8000-R-AUTO is a CAN/LIN serial bus trigger and analysis option for DS8000-R series oscilloscopes, supporting frame detection and error analysis up to 5 Mb/s.
Product details
| Model | DS8000-R-AUTO |
| Manufacturer | RIGOL |
| Category | Oscilloscope Accessories |
| Availability | Made to order |
Description
Overview
The RIGOL DS8000-R-AUTO is a CAN/LIN serial bus trigger and analysis option for RIGOL DS8000-R series oscilloscopes. This option provides comprehensive CAN and LIN bus signal decoding and triggering capabilities for automotive and industrial applications.
Key Features
- CAN bus support with data rates up to 5 Mb/s
- Multiple CAN signal types: CAN_H, CAN_L, TX/RX, and differential
- LIN bus support for automotive networks
- Frame-level triggering: frame start, frame end, Remote ID, and overload detection
- Error detection: frame error, answer error, check error, format error, bit fill, and random errors
- Frame data and ID-based triggering
- Multi-channel support: CH1 through CH4
Applications
- Automotive CAN/LIN bus testing and debugging
- CAN network signal integrity verification
- Automotive communication protocol validation
- Industrial control system bus analysis
Specifications
| Series | DS8000-R Series |
