Keysight N7000A InfiniiMax III+ Probe Amplifier

Overview

The Keysight N7000A is an 8 GHz bandwidth-enhanced amplifier in the InfiniiMax III+ series, designed for general-purpose, high-speed differential bus probing. It features InfiniiMode technology, which greatly expands the measurement capabilities of the probe, enabling engineers to measure all components of a differential signal from a single connection.

Key Features

• 8 GHz bandwidth for high-speed differential bus probing
• InfiniiMode technology for expanded measurement capabilities
• Compatible with all InfiniiMax III/III+ accessories and QuickTip head
• Loaded with measured S-parameters for more accurate AC correction
• Direct connection to Infiniium 90000X/Q and V-Series oscilloscopes (software ver 5.50 or higher)
• Ability to measure differential signal, single-ended A or B signals, and common-mode component
• Unique S-parameter data for more accurate probe correction and measurement

Applications

• High-speed differential signal measurement and analysis
• Oscilloscope probing for advanced test equipment
• Signal integrity analysis and characterization
