Keysight N1811TL Coaxial Switch
Request a quote
Keysight N1811TL — 4-port terminated bypass latching coaxial switch for DC-26.5 GHz with excellent isolation and 2 million cycle lifespan.
Product details
| Model | N1811TL |
| Manufacturer | Keysight |
| Category | Oscilloscope Accessories |
| Availability | Made to order |
Description
Overview
The Keysight N1811TL is a 4-port terminated bypass latching coaxial switch designed for RF and microwave applications from DC to 26.5 GHz. The switch's internal load can terminate the device under test (DUT) when in bypass mode at power levels up to 1 watt. Its compact design makes it ideal for drop-in and dropout applications where space is limited.
Key Features
- Frequency range: DC to 26.5 GHz
- 4-port terminated bypass configuration with female SMA connectors
- Internal 50 Ω load for DUT termination up to 1 watt
- Superior isolation: >120 dB at 4 GHz, 70 dB at 26.5 GHz
- Low insertion loss: <0.27 dB at 4 GHz, 0.80 dB at 26.5 GHz
- Excellent insertion loss repeatability: 0.03 dB to 1 million cycles, 0.1 dB to 2 million cycles
- Operating life: 2 million cycles
- Low SWR: <1.10 at 4 GHz, 1.60 at 26.5 GHz
- Coil voltage options: 5 V, 15 V, or 24 V
- D-subminiature 9-pin connectors or solder lug terminals available
- Standard or TTL/5 V CMOS compatible drive options
- Compact, drop-in design
- Optional position indicators
- Built-in current interrupt
Applications
- Precision measurement and monitoring systems
- RF and microwave test and measurement equipment
- High-frequency bypass switching and signal routing
- Device-under-test (DUT) termination and protection
- Space-constrained test setups
Specifications
| Type | Terminated 4-port bypass switch Female SMA connectors Built-in current interrupt |
| Superior RF Performance | Superior isolation: > 120 dB at 4 GHz and 70 dB at 26.5 GHz Low SWR: < 1.10 at 4 GHz and 1.60 at 26.5 GHz Low insertion loss: < 0.27 dB at 4 GHz and 0.80 dB at 26.5 GHz |
| Excellent RF Repeatability And Long Life Span | Excellent insertion loss repeatability: 0.03 dB to 1 million cycles and 0.1 dB to 2 million cycles Long operating life of 2 million cycles |
| N1811TL | Terminated Latching: The N1811TL is a terminated bypass switch available in the frequency range from DC to 26.5 GHz. The switch’s internal load can terminate the device under test when in the bypass mode (up to 1 watt). Because of its compact design, it is ideal for drop-in, dropout applications. |
