Tektronix AFG3102C Arbitrary Function Generator
Request a quote
Tektronix AFG3102C is a 2-channel 100 MHz arbitrary function generator with 14-bit resolution and 1 GS/s sampling.
Product details
| Model | AFG3102C |
| Manufacturer | Tektronix |
| Category | Multimeters & DMMs |
| Availability | Made to order |
Description
Overview
The Tektronix AFG3102C is a 2-channel arbitrary function generator in the AFG3000C series, providing 1 µHz to 100 MHz sine waveform generation with 14-bit resolution and up to 1 GS/s arbitrary waveform sampling. The instrument features a large 5.6-inch display, modern touch-screen interface, and comprehensive connectivity for research, education, and embedded system testing.
Key Features
- 2-channel 100 MHz sine waveforms
- 14-bit arbitrary waveforms at 1 GS/s sampling rate
- Output amplitude up to 20 Vp-p into 50 Ω loads
- Modulation modes: AM, FM, PM, FSK, PWM
- Sweep and burst capabilities
- 5.6-inch capacitive touchscreen display
- USB, GPIB, and LAN connectivity
- LabVIEW and LabWindows/IVI-C drivers
Applications
- Analog and digital circuit testing
- Function verification and performance characterization
- Embedded system design and validation
- Research and education
Specifications
| Channel/Port Count | 2 |
| High Frequency (range) | 10MHz <= 100MHz |
