Keithley 8010 High Power Device Test Fixture

Overview

The Keithley 8010 is a high power device test fixture that enables safe and easy connections for testing packaged high power devices at voltages up to 3000V and currents up to 100A. It provides comprehensive connectivity and protection for multi-terminal devices including diodes, transistors, and more complex semiconductor packages. The fixture integrates with multiple SourceMeter SMU instruments and includes built-in protection circuits against device faults.

Key Features

• High voltage capability: up to 3000V
• High current capability: up to 100A
• Supports up to six SourceMeter SMU instruments with full interlock capability
• Integrated protection circuits for low-voltage SMU instruments
• Multiple replacement socket modules (TO-247, TO-220, axial lead, custom blank)
• Rear-panel scope and thermal probe ports for system integration
• Standard banana jumper connections

Compatible Instruments

• Keithley Model 2657A High Voltage SourceMeter SMU
• Keithley Model 2651A High Current SourceMeter SMU (one or two units)
• Keithley Series 2600B Source Measure Unit (SMU)
• Keithley Model 4200-SCS Source Measure Unit (SMU)

Applications

• Diode device characterization
• Transistor testing and evaluation
• Multi-terminal semiconductor device testing
• Power device characterization
• High-voltage and high-current semiconductor testing
