Keithley 2420 SourceMeter SMU
Request a quote
Keithley 2420 is a 60V/3A/60W SourceMeter SMU with 4-quadrant source/measure capability, 0.012% accuracy, and 6½-digit resolution for parametric testing.
Product details
| Model | 2420 |
| Manufacturer | Keithley |
| Category | Multimeters & DMMs |
| Availability | Made to order |
Description
Overview
The Keithley 2420 is a SourceMeter SMU (Source Measure Unit) that combines precision voltage and current source capability with a 6½-digit multimeter. It provides four-quadrant source and measurement operation, making it suitable for parametric testing and characterization of semiconductor components and modules in research and production environments.
Key Features
- Four-quadrant precision voltage and current source/load operation
- 60V maximum voltage, 3A maximum current, 60W maximum power
- 0.012% basic measurement accuracy with 6½-digit resolution
- 1700 readings/second at 4½ digits via GPIB interface
- 2-, 4-, and 6-wire remote sensing for voltage measurement
- Programmable DIO port for automation and handler control
- Standard SCPI, GPIB, RS-232, and Keithley Trigger Link interfaces
- Pass/Fail comparator for fast sorting and binning
Applications
- Semiconductor component and module characterization
- Production parametric testing and device validation
- IV curve measurement and analysis
- Component reliability and failure analysis
- Power supply and power semiconductor testing
Specifications
| High Frequency (range) | 1kHz <= 100kHz |
