Rohde & Schwarz LCX100 Digital LCR Meter
Request a quote
Rohde & Schwarz LCX100 LCR meter spans 4 Hz to 300 kHz with ±0.05% impedance accuracy, data logging, and adjustable DC bias for development and production applications.
Product details
| Model | LCX100 (3629.8856.02) |
| Manufacturer | Rohde & Schwarz |
| Category | LCR & Impedance Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz LCX100 is a precision LCR meter designed for demanding applications in research, development, and production testing. It measures impedance from DC and 4 Hz to 300 kHz with exceptional accuracy, making it ideal for component characterization, material analysis, and fast production testing.
Key Features
- Frequency range from DC, 4 Hz to 300 kHz
- Basic accuracy of ±0.05% for impedance measurements
- Basic accuracy of ±0.03° for phase measurements
- DC bias voltage up to 40 V (internal 10 V, external up to 40 V)
- Data logging function with up to 10 samples per second via USB or LAN
- Multiple measurement times: Fast (≤15ms), Medium (≤100ms), Slow (≤500ms)
- Selectable output impedance of 100Ω or 10Ω
- Measurement range from 100 mΩ to 100 MΩ
Applications
- Component characterization and material analysis in research and development
- Fast production testing and quality assurance
- Impedance measurements under DC bias conditions
- Low and extremely high impedance applications
Specifications
| High Frequency (range) | 100kHz <= 1MHz |
