GW Instek LCR-8110G High Precision LCR Meter
Request a quote
GW Instek LCR-8110G is a 10MHz high precision LCR meter with 0.1% basic accuracy, large LCD display, multi-step function, and GPIB/RS-232C interfaces.
Product details
| Model | LCR-8110G |
| Manufacturer | GW Instek |
| Category | LCR & Impedance Analyzers |
| Availability | Made to order |
Description
Overview
The GW Instek LCR-8110G is a 10MHz high precision LCR meter from the LCR-8000G Series. It delivers accurate component measurements with a test frequency up to 10MHz, 0.1% basic accuracy, 6-digit resolution, and intuitive user interface with large LCD display.
Designed for versatile component measurement applications, the LCR-8110G supports DC resistance measurement, voltage/current monitoring, multi-step measurement programming, and graphical analysis with frequency or voltage sweep modes for impedance response evaluation.
Key Features
- Test frequency: 20 Hz to 10 MHz
- 0.1% basic accuracy with 6-digit measurement resolution
- Large LCD display with intuitive interface
- Full measuring functions with DUT V/I monitor
- DC resistance measurement capability
- Multi-step mode for customized measurement sequences
- PASS/FAIL function with absolute, percentage, or delta judgment and alarm
- Graph mode for impedance vs. frequency and impedance vs. voltage analysis
- Standard RS-232C and GPIB interfaces for PC control and result display
- Optional DC bias box for extended measurement capabilities
Applications
- Quality Control and Incoming Inspection
- Research and Development
- Passive component characterization
- Production testing and verification
Specifications
| High Frequency (range) | 10MHz <= 100MHz |
