PCE Instruments PCE-EMD 5 Temperature and Humidity Indicator

Overview

The PCE-EMD 5 is a wall-mounted indicator for displaying temperature and humidity from multiple external sensors. It connects to up to four sensor modules simultaneously, automatically recognizing each connected sensor and displaying the average reading across all active sensors. The 100 mm digits provide visibility from a distance, making it suitable for monitoring ambient conditions in event venues, restaurants, and public buildings.

Key Features

• Temperature measuring range: 0.0–50.0°C
• Humidity measuring range: 0.0–99.9% RH
• Digit height: 100 mm (3.9 inches)
• Multi-sensor support: up to four external sensors with automatic recognition
• Analog 4–20 mA signal communication with sensors
• Integrated sensor power supply: 12 or 24 V DC
• Power supply: 110–220 V AC (mains)
• Optional VESA mounting bracket (75 × 75 mm)

Applications

• Event halls and conference centers
• Restaurants and hospitality venues
• Public buildings and offices
• Museums and galleries with climate control requirements

Included Accessories

• 1x Sensor module (PCE-EMD-TH)
• 2x Wall mounting brackets
• User manual
