Fluke FLUKE-750R08 Pressure Module
Request a quote
FLUKE-750R08 is a reference-grade pressure module for Fluke calibrators, measuring 0 to 1000 psi (0 to 70 bar) with reference accuracy.
Product details
| Model | FLUKE-750R08 |
| Manufacturer | Fluke |
| Category | Digital Pressure Gauges |
| Availability | Made to order |
Description
Overview
The Fluke FLUKE-750R08 is a reference-grade pressure module designed to extend the capabilities of Fluke multifunction calibrators. It provides independent calibration and reference-level accuracy for pressure measurement up to 1000 psi (70 bar, 7000 kPa). The module can be swapped between calibrators without loss of accuracy or traceability.
Key Features
- Reference-grade accuracy for precision pressure measurement
- Pressure range: 0 to 1000 psi (0 to 70 bar, 0 to 7000 kPa)
- 316 stainless steel wetted parts for durability
- No-tools-required connectors for easy connection
- Independent calibration with traceable certificate included
- Burst rating: 4X rated pressure
- Includes NPT, metric (BSP) and M20 adapters
- Compatible with Fluke 725, 726, 750 Series and other multifunction calibrators
Applications
- Pressure calibration and measurement in test and measurement labs
- Industrial process control calibration
- Extending measurement range of existing Fluke calibrators
Included Accessories
- 750R08 Reference Pressure Module
- Traceable calibration certificate
- Adapters (NPT, BSP, M20)
- Manual
Specifications
| Series | 750P Series |
