Fluke 750PD3 Pressure Module
Request a quote
Fluke 750PD3 pressure module for multifunction calibrators, ±0.06% accuracy, -5 to 5 psi range.
Product details
| Model | FLUKE-750PD3 |
| Manufacturer | Fluke |
| Category | Digital Pressure Gauges |
| Availability | Made to order |
Description
Overview
The Fluke 750PD3 is a dual-range pressure module that transforms Fluke multifunction calibrators into full-fledged pressure calibrators. With a measurement range of -5 to 5 psi (-350 to 350 mbar / -35 to 35 kPa), it extends the pressure measurement capabilities of Fluke calibrators while maintaining independent calibration, allowing swapping between instruments without loss of accuracy.
Key Features
- Measurement range: -5 to 5 psi (-350 to 350 mbar, -35 to 35 kPa)
- Total uncertainty: ±0.06% (1-year, 15°C to 35°C)
- Reference uncertainty: ±0.03%
- Burst rating: 4X
- High-side media: 316 stainless steel
- Low-side media: dry air
- No-tools-required connectors
- Displays pressure in up to 11 engineering units
- Compatible with Fluke 725, 726, and 750 Series calibrators
Applications
- Precision pressure measurement and calibration
- Field pressure testing and verification
- Extending measurement range of existing calibrators
- Compliance documentation with quality standards
