Fluke FLUKE-717 5000G Pressure Calibrator
Request a quote
Fluke FLUKE-717 5000G pressure calibrator with 0.05% accuracy, 5000 psi range, integrated dual pressure/current measurement, and comprehensive switch testing.
Product details
| Model | FLUKE-717 5000G |
| Manufacturer | Fluke |
| Category | Digital Pressure Gauges |
| Availability | Made to order |
Description
Overview
The Fluke 717 5000G is a portable pressure calibrator designed for field and laboratory use. It combines pressure measurement with simultaneous current measurement, enabling technicians to calibrate pressure gauges and pressure switches with precision. The rugged, compact design makes it ideal for on-site maintenance and process control applications.
Key Features
- Measure pressure with 0.05% accuracy of full scale (0–5000 psi / 0–345 bar)
- Simultaneous pressure and current measurement for complete P/I instrument calibration
- Measure and source 24V loop power for transmitter testing
- Measure current with 0.015% accuracy and 0.001 mA resolution
- Pressure switch test function to capture set, reset, and deadband values
- 1/8 NPT female pressure fitting for standard industrial connections
- Select from 11 different engineering units (PSI, bar, kPa, mbar, inH2O, etc.)
- Zero, min, max, and hold functions for flexible operation
- EMI tolerant and dust/splash resistant design for harsh environments
- Long-lasting battery life with removable battery door for quick changes
- Compatible with Fluke 700Pxx pressure modules for measurement up to 10,000 psi/700 bar
- Compatible with Toolpack magnetic hanging system for hands-free operation
Applications
- Calibrating pressure gauges and transducers in process systems
- Testing pressure switches for proper set and reset values
- Commissioning and troubleshooting pressure instruments
- Field maintenance of instrumentation in oil, gas, and manufacturing facilities
- Verifying 4–20 mA pressure transmitters with simultaneous current measurement
Included Accessories
- Protective yellow holster with test lead storage
- Multi-language instruction sheet
- 9V alkaline battery
- Test leads and alligator clips
- NIST-traceable calibration report and data
Specifications
| Pressure Range | 0 to 5000 psi (0 to 345 bar) |
| Pressure Accuracy | 0.05% of full scale |
| Current Measurement Accuracy | 0.015% |
| Current Resolution | 0.001 mA |
| Pressure Connection | 1/8 NPT female |
| Loop Power Supply | 24V sourcing |
| Engineering Units | 11 units (PSI, bar, kPa, mbar, inH2O, mmHg, inHg, kg/cm², lb/in²) |
| Battery | 9V alkaline |
| Environmental Rating | EMI tolerant, dust and splash resistant |
| Optional Pressure Modules | 29 Fluke 700Pxx modules available (0–10,000 psi / 0–700 bar range) |
| Functions | Zero, min, max, hold, pressure switch test |
