Fluke 700RG07 Reference Pressure Gauge
Request a quote
Fluke 700RG07 is a high-accuracy reference pressure gauge with ±0.01% FS accuracy, -12 to 500 psig range, IP67 rating, and data logging.
Product details
| Model | FLUKE-700RG07 |
| Manufacturer | Fluke |
| Category | Digital Pressure Gauges |
| Availability | Made to order |
Description
Overview
The Fluke 700RG07 is a high-accuracy reference pressure gauge designed for pressure calibration and measurement applications. With ±0.01% full scale accuracy and a range of -12 to 500 psig, it provides precise readings for both hydraulic and pneumatic systems. The rugged sealed enclosure with IP67 rating ensures reliable performance in demanding test environments.
Key Features
- Pressure range: -12 to 500 psig (-0.83 to 34 bar)
- Accuracy: ±0.01% full scale (positive pressure), ±0.05% full scale (vacuum)
- Resolution: 0.01 psi, 0.001 bar
- Burst pressure: 2000 psi (138 bar)
- 5-1/2 digit display with 20-segment bar graph (0 to 100%)
- Data logging: up to 8,493 measurements (requires optional 700G/TRACK software)
- Rugged sealed enclosure with IP67 rating
- CSA Class 1, Division 2, Groups A-D rating
- ATEX rating: II 3 G Ex nA IIB T6
- User-configurable: sample rate, tare, damper, auto-off, units selection, max/min
- Three-year warranty
Applications
- Pressure calibration and testing for hydraulic systems
- Precision measurement for pneumatic systems
- Reference standard for pressure gauge calibration
- Laboratory and field pressure testing
Included Accessories
- Manual on CD-ROM in 14 languages
- Traceable certificate of calibration
- 1/4-inch NPT to 1/4-inch ISO adapter
Specifications
| Series | 700G Series |
