Fluke 2700G-BG3.5M Reference Pressure Gauge

Overview

The Fluke 2700G-BG3.5M is a high-precision digital reference pressure gauge designed for calibration and pressure measurement applications requiring 0.02% full-scale accuracy. The gauge operates within a range of -12 psi to 500 psi (-80 kPa to 3.5 MPa) with a resolution of 0.01 psi (0.001 bar) and can withstand burst pressures up to 2000 psi (14 MPa). It features a 5-1/2 digit display and 20-segment bar graph for easy reading, along with user-configurable functions including sampling rate, tare, damping, and auto-off settings.

Key Features

• 0.02% full-scale accuracy (positive pressure) / 0.05% (vacuum)
• Range: -12 to 500 psi (-80 to 3.5 MPa)
• Resolution: 0.01 psi (0.001 bar)
• 5-1/2 digit display, 20-segment bar graph
• Burst pressure rating: 2000 psi (14 MPa)
• 1/4 inch NPT male connection
• Three AA alkaline batteries (75-hour life)
• USB communications and universal power supply included
• Choice of 21 standard engineering units (bar, psi, kPa, MPa, in H2O, etc.)

Applications

• Calibrating pressure gauges, transmitters, transducers, and switches
• Serving as a standard for verification and checks
• Process pressure measurement with data logging capabilities
• Portable and bench-top pressure testing solutions

Included Accessories

• Manual in 14 languages
• Calibration certificate showing traceability
• 1/4 NPT female to 1/4 BSP male adapter
• 1/4 NPT female to M20X1.5 adapter
• Universal AC power supply
• USB communication cable
