Keysight N8921A DC Power Supply
Request a quote
Keysight N8921A is a 5kW programmable DC power supply with autoranging output for 0-200V and 0-70A combinations, ideal for mid-voltage ATE and power testing applications.
Product details
| Model | N8921A |
| Manufacturer | Keysight |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The Keysight N8921A is a 5kW programmable autoranging DC power supply in the N8900 Series. It provides flexible voltage and current combinations (0-200V, 0-70A) at full power output, making it ideal for mid-voltage testing applications. Designed for automated test equipment (ATE) systems, it delivers high power density in a compact 3U form factor with integrated measurement and comprehensive protection features.
Key Features
- 5000W output power, 0-200V / 0-70A autoranging output
- Flexible voltage-current combinations at full power
- Only 3U (5.25 in / 13.34 cm) tall, high power density design
- Built-in voltage and current measurement
- LAN (LXI Core), USB, GPIB, and analog interface options
- Over-voltage, over-current, and over-temperature protection
- Single-phase AC input: 187-240V
- Expandable to 100 kW by paralleling multiple units
- Three-year warranty
Applications
- Automated test equipment (ATE) systems
- Mid-voltage power supply testing
- Power conversion and efficiency testing
- Battery and energy storage system testing
- Production quality assurance environments
Specifications
| Voltage Range Selector | 200-299 |
| Output Voltage | 200 V |
| Current Range Selector | 50-99.9 |
| Output Current | 70 A |
| Power Range Selector | 5,000-9,999 |
| Power Rating | 5 kW |
| Mounting Type | Rack Mount |
| Input Voltage | 208 VAC |
| Series | N8900 Series |
| Display | Digital |
| Interface | GPIB,USB,LAN |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 3U |
| Special Features | Autoranging, Master/Slave Modes |
