Keysight N6952A Advanced Power System

Overview

The Keysight N6952A is a 1 kW advanced DC power supply in the N6900 Series, designed for automated test equipment (ATE) applications where high performance is critical. Rated at 40V, 25A output, the N6952A delivers test speeds 100 times faster than standard system power supplies with exceptional power delivery control.

Key Features

• Output: 40V, 25A (1 kW total)
• Command processing speed under 2ms
• Fast programming speeds up to 3ms for voltage and current
• Dual voltage and current measurement with DMM-like accuracy
• Power, peak power, watt-hour, and amp-hour measurements
• VersaPower architecture for flexible test system configuration
• Optional parallel operation up to 10 kW with equal current sharing

Configurable Options

• Option 301: Accuracy Package — improved programming and measurement accuracy
• Option 302: Measurement Enhancements — external data logging and voltage/current digitizers
• Option 303: Source and Speed Enhancements — arbitrary waveforms and output list capability
• Options 760 & 761: Disconnect and Polarity-Reversal Relays for DUT protection

Applications

• High-volume automated test equipment (ATE) systems
• Power supply testing and characterization
• Device under test (DUT) validation and burn-in
• Dynamic power profiling and inrush current capture
