Keysight N6701A Modular Power System Mainframe

Overview

The Keysight N6701A is a 600 W, 1U high modular power system mainframe designed for automated test equipment (ATE) systems requiring multiple power sources. It accepts up to 4 interchangeable N6700 series DC power modules, enabling flexible configuration of voltage, current, and performance specifications. The system is suitable for applications that need more total power capacity than the N6700C 400 W mainframe.

Key Features

• 600 W total output power capacity in compact 1U form factor
• 4-slot modular design accepts 1 to 4 N6700 series DC power modules
• Standard interfaces: GPIB, LAN (LXI Core compliant), and USB
• Power management feature allows custom power allocation per module
• Programmable voltage and current with overvoltage protection
• Fast command processing and settling times
• AC input range: 86 VAC to 264 VAC, 50/60/400 Hz
• Inhibit input response time less than 5 microseconds

Applications

• High-power automated test equipment (ATE) systems
• Multi-output power supply configurations for complex testing scenarios
• Production test environments with elevated power requirements
