Keysight E4360A Solar Array Simulator Mainframe
Request a quote
Keysight E4360A solar array simulator mainframe — 2 slots, up to 1200W, 2U height, with LAN, USB, GPIB, and LXI interfaces.
Product details
| Model | E4360A |
| Manufacturer | Keysight |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The Keysight E4360A is a modular solar array simulator mainframe designed for testing and development of solar power systems. It provides a 2-slot architecture that accommodates up to two E4360 series modules (sold separately), delivering up to 1200W of total output in a compact 2U-high form factor. The mainframe features standard interfaces including LAN, USB, GPIB, and LXI support for seamless integration into test systems.
Key Features
- 2-slot modular architecture supporting up to 2 E4360 series modules
- Maximum total output power: 1200W (200-240VAC input) or 600W (100-120VAC input)
- Compact 2U-high form factor for space-efficient laboratory deployment
- Standard interfaces: LAN, USB, GPIB, and LXI for test system integration
- Fast protection response: 5µs inhibit response, <10µs fault detection on coupled outputs
- SCPI command support for easy programming
- Includes 14360A System Control Tool software for multi-instrument control
Applications
- Satellite power system testing and validation
- Residential and utility-scale photovoltaic (PV) system testing
- Solar array characterization and simulation
Specifications
| Power Rating | 1200 W |
| Input Voltage | 100-240 VAC |
| Type | Mainframe |
| Rack Space | 2U |
| Series | E4360 Series |
| Interface | GPIB, LAN, LXI, USB |
| Number of Outputs | 2 |
| Programmable | Yes |
